The ultimate all-aluminum 6-seater bush plane, built to conquer the backcountry with massive cabin space and short-field power.
Configuration:
The 6-seat setup is the default design configuration for most builders. Because the cabin is 44-46 inches wide and features 13 feet of flat floor, a 6-seat setup makes the plane feel incredibly spacious.
- The Layout: Two adjustable front bucket seats and a single row behind them. The middle/rear seats are mounted on rails and can be detached by pulling a few quick-release pins.
- Passenger Boarding Access: Dual front cockpit doors supplemented by an oversized 35-inch side cargo door for row 2 and 3 boarding.
- Weight & Balance Advantage: The Moose is designed with a naturally heavy nose to support larger radial or turbine powerplants. Keeping the rear cabin open allows you to stack heavy cargo right over or slightly behind the Center of Gravity (CG), keeping the plane highly stable.
Build Kit:
- Complete Airframe Kits
- Plans and Instructions Included
- Excluded- Engine, Engine Mount, Instruments, Upholstery, Restraints and Paint
Flight Performance:
| Climb Rate | 1200-1500 ft per minute |
| Cruise Speed | 145-150 mph |
| Landing Roll | 600-800 ft |
| Max Speed | 170 mph |
| Stall Speed | 50 mph |
| STOL | 600 Ft |
Specifications:
| Cockpit Width | 44-46 inches |
| Construction Time | |
| Cord | |
| Design Loads | |
| Empty Weight | 816 kg |
| Engine HP Range | 550 HP |
| Gross Weight | 1587 kg |
| Fuel Capacity | Partial Fuel Required if carrying 6 large adults |
| Gross Weight | |
| Headroom | |
| Length | 7.01 m |
| Height | 1.98 m |
| Cabin Width | 1.14 m |
| Seat(s) | 6 |
| Tail Span | |
| Wing Area | 16.91 m2 |
| Wingspan | 10.97 m |
| Top Level Speed | |
| Velocity-Never Exceed | 304 km/h |
